Description
WIDOS 3511 Plastic Welding Machine – Reconditioned
The WIDOS 3511 is a German-built socket fusion welding machine for butt-welding thermoplastic pipes such as PE, PP, and PVDF. This 2020 model has been reconditioned, tested, and is ready for industrial use. Machine is sold as pictured – includes the attached clamping system and heating plate only. Inserts and optional large welding device for sizes above 63 mm are not included.
Features
- Designed for socket fusion welding of PE, PP, and PVDF pipes
- Pipe OD capacity: 20–125 mm (up to 150 mm with optional tooling)
- Manual/pressure operation with stable clamping system
- Reconditioned 2020 model, tested for full functionality
- Rugged steel and aluminum construction
- Single-phase 110 V, 60 Hz operation
Included
- WIDOS 3511 base unit
- Attached clamping system
- Attached heating plate
Specifications
| Brand | WIDOS |
|---|---|
| Model | 3511 |
| MPN | 3750110US |
| Voltage | 110 V |
| Current | 10 A |
| Frequency | 60 Hz |
| Pipe Diameter Range | 20–125 mm (up to 150 mm with optional tooling) |
| Year Built | 2020 |
| Serial Number | G0320068 |
Dimensions
| Length | 44 in |
|---|---|
| Width | 30 in |
| Height | 30 in |
| Weight | 103 lbs (47 kg) |
