Crosby G-2160 Sling Shackle – 40-Ton Rating, Wide-Body Design, Refurbished

Description

Crosby G-2160 Wide Body Sling Shackle – 40 Ton WLL – #1021285 Reconditioned w/ 1 Year Operational Warranty

Description:

Increase in shackle bow radius provides minimum 58% gain in sling bearing surface and eliminates need for a thimble

Increases usable sling strength a minimum of 15% and greatly improves life of wire rope slings

Can be used to connect synthetic web slings, synthetic round slings or wire rope slings

All sizes Quenched & Tempered for maximum strength

Forged alloy steel from 7 through 300 metric tons

Cast alloy steel from 400 through 1550 metric tons

Proof tested as follows:

7 through 75 metric tons and 200 through 300 metric tons: 2 x WLL

125 metric tons: 1.6 x WLL

400 metric tons and higher: 1.33 x WLL

All ratings are in metric tons, embossed on side of bow

G-2160, (7 through 55t), are hot-dip galvanized and pins are painted red

G-2160 (75t and larger), bows are furnished Dimetcoted; Pins are Dimetcoted, then painted red

Shackles 30t and larger are RFID equipped

Approved for use at -40° C (-40° F) to 204° C (400° F)

Bow and bolt are certified to meet Charpy impact testing of 42 Joules (31 ft-lb) min. avg. at -20° C (-4° F)

All 2160 shackles are individually proof tested and magnetic particle inspected. Crosby certification available at time of order

Shackles requiring ABS, Lloyds and other certifications are available upon special request and must be specified at time of order

Type approved and certification to DNV Rules for Certification of Lifting Appliances, and are produced in
accordance with DNV MSA requirements; databook is provided that includes required documents:

Serialization / Identification

Material Testing (physical / chemical / Charpy)

Proof Testing

Look for the Red Pin… the mark of genuine Crosby quality
